M90UHD Mech Arm Visualiser 13MP UHD 322X Zoom Flagship Ultra HD Visualiser

AVerVision M90UHD

See a World in a Grain of Sand
Mechanical Arm Visualizer (Document Camera). The M90UHD is a visualizer with an impressive lineup of features that include a 13-megapixel camera, 4K imaging, and a transcendent 322X total zoom capacity. These characteristics help teachers demonstrate all types of materials in an extraordinarily vivid way. What’s more, intuitive function buttons, an extendable arm, and AVerTouch software allow teachers of any subject to create fantastic collaborations in next to no time.
14X Optical Zoom
4K Ultra HD
13 MP
60fps
A3 Shooting Area
HDMI / VGA / USB Outputs
The Only 322X Total Zoom. Equipped with a 14X optical and 23X digital zoom, the M90UHD’s amazing 322X total zoom buries the competition. Every student—even the ones in the back row—can enjoy a wonderful learning journey without missing a single detail. Splendid 4K Image Quality: Ultra HD output resolution and 13 megapixels display every subtle detail of topographical maps, chemical experiments, stereo models, and more. This clarity improves teaching quality and enhances student comprehension. One-Push Recording, Capturing, and Playback: Intuitive recording and capturing enable users to record the complete teaching process with one button. Also, the playback function lets teachers review their lessons and examine student behaviour to successfully prevent any accidents. Massive A3 Shooting Area: A larger-than-A3-size shooting area captures items as big as building models. In addition, the position indicator on the camera head helps teachers always display materials accurately. Multiple Ports Fit Any Device. With HDMI, VGA, and USB jacks available, users can connect the M90UHD to any display or computer and use the devices they’re most familiar with to teach. Super-Efficient Mechanical Arm: Featuring a low centre of gravity and a fully adjustable, neatly foldable mechanical arm, the visualizer is easy to operate with only one hand and takes up minimal storage space. Rapid Autofocus Banishes Blur. Some visualizers have a difficult time focusing on moving objects, but not this one. A single press of a button activates a premium-quality autofocus function that instantly clarifies the image and maintains students’ attention. Embedded Light: The M90UHD offers an embedded light for adjusting luminance. Even in a dark presentation environment, teachers can easily provide a comfortable viewing experience. AVerTouch Software: Take Your Ideas Anywhere. AVerTouch is ultra-powerful software designed exclusively for AVer visualizers. One touch connects your visualizer with mobile devices for content sharing, and you can sync to the cloud to automatically save annotated, captured, and recorded files. Teaching is incredibly fun when you use AVerTouch to engage with your students.
Specifications

Image Sensor: 1/3.06" CMOS
Total Pixels: 13 Megapixels
Output Resolution:4K
Full HD 1080p 60Hz
HD 720p 60Hz

TV Lines: 1,400
Zoom: 322X
Total Zoom: (14X Optical Zoom x 23X Digital Zoom)
Frame Rate: 60fps (max.)
Focus: Auto / Manual
Shooting Area: A3 (420 x 315 mm max.)
Image Rotation:Electronic: 0°, 180°
Mechanical: 0°, 90°, 180° (Camera Head)

Internal Storage: 200 Pictures at XGA (1024 x 768)
External Storage: Micro SD Card & USB Thumb Drive (FAT32 / 32 GB)
One-touch Recording: Yes
One-touch Capturing: Yes
Image Effects: Colour
B&W
Negative

Image Adjustments (White Balance / Exposure): Auto / Manual
Display Modes: Normal
Motion
High Quality
Microscope
Macro
Infinity

Capture Modes: Single
Continuous

User Profiles: Yes, up to 3
Timer: Yes
Flicker Filter Control: Yes
ePTZ: Yes
Light Source: Embedded LED Lamp
HDMI I/O:1 in
1 out

VGA I/O:1 in
1 out

USB 2.0 Ports: Type-A x 1 (USB Thumb Drive)
Type Mini-B x 1 (PC)

Audio: Line out (3.5 mm)
Mic in (3.5 mm)
Built-in Mic
HDMI

Security: Kensington Slot
RS-232 Port (Optional): Mini-DIN Jack (Available for M90UHD with RS-232 Only)
Dimensions (W x D x H):Operating: 159.0 x 481.3 x 469.9 mm
Folded: 176.0 x 319.0 x 112.0 mm

Net Weight: 2.2 kg (4.85 lbs.)
Power Source: DC 5V / 3A
AC 100 to 240V, 50 / 60Hz

Power Consumption:10 Watts (Lamp on)
9 Watts (Lamp off)

Warranty:Visualizer: 5 Years
Accessories: 1 Year

Software: AVerTouch
Windows®OS: Windows® 7, 10, 11
Mac® OS: Mac® 10.15, 11, 12
Chrome™ OS: Chrome™ OS 75 or Later (Available via the Sphere Lite App Only)
Optional Accessories: Microscope Adaptor
Connecting Plate for Microscope Adaptor
Anti-Glare Sheet
Carrying Bag
RS-232 Cable

Package Contents: AVerVision M90UHD Unit
USB Cable
VGA Cable
Power Cable
Power Adapter (5V / 3A)
Remote Control with AAA Batteries x 2
Warranty Card
Quick Start Guide
CD1
